Specifications
- Manufacturer: KTM
- Model: FREERIDE E
- Year: 2027
- Type: Electric
- Electric motor: 50,4 V - PMSM
- Max. power: 19,2 kW
- Torque: 37.6 Nm
- Max. motor speed: 12000 rpm
- Battery capacity: 110 Ah
- Charging time 100 %: 480 min.
- Rated output: 8,3 kW
- Secondary gear ratio: 13:50
- Traction battery: MX50 Lithium-Ion Battery
- Charger line voltage: 90 - 265 V / 50 - 60 Hz
- Charging power: 660 W
- Charging time 80 %: 360 min.
- Frame design: Chrome-molybdenum steel frame
- Rear subframe design: Aluminium / Polyamide Glass Fiber
- Handlebar: Pro Taper, Aluminium Ø 28/22 mm
- Front brake: Disc brake
- Rear brake: Disc brake
- Front brake disc diameter: 260 mm
- Rear brake disc diameter: 220 mm
- Wheels: 1.60 x 21"; 2.15 x 18"
- Tyre width (front): 90
- Tyre height (front): 90
- Tyre width (rear): 120
- Tyre height (rear): 90
- Tyre dimensions (front/rear): 90/90; 120/90
- Chain: 520, Non-sealed
- Steering head angle: 65.6 °
- Front suspension: WP XACT USD Fork
- Rear suspension: WP XPLOR shock absorber with PDS
- Suspension travel (front): 250 mm
- Suspension travel (rear): 240 mm
- Steering head angle: 65.6 °
- Fork offset: 20 mm
- Seat height: 910 mm
- Weight (without fuel): 112 kg
- Wheelbase: Fehlende Variable
- Ground clearance: 360 mm
